High Fidelity Stereo Switching Power Amplifier FP 14000Q DJ Audio Amplifier Sound System

Product Categories

Guangzhou DUBAO Electronics Technology Co., Ltd.

Contact Now

Brand Name : QYC

Model Number : FP-14000Q

Certification : CE , RoHS

Place of Origin : China

MOQ : 2 Pieces

Price : Negotiable

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 500 Pieces/Month

Delivery Time : Within 15 Days

Packaging Details : Carton Packing or Flight Case

8Ω : 2400 W x 2

Frequency Response : 20 Hz - 25000 Hz

THD+N : < 0.001

Signal-Noise Ratio : > 110 dB

Input Impedance : 20KΩ

Damping Factor : 800

Weight : 13 kg

Contact Now

High Fidelity Stereo Switching Power Amplifier FP 14000Q DJ Audio Amplifier Sound System

FP 14000Q Professional Switching Power Amplifier

2-way Signal Input Selection, Music Effect Direct Connection Function

Professional Digital Reverberation IC Processing Chip

2-way Microphone Input, Each way of Microphone with Separate High Pitch, Alto Voice and Bass Adjustment
Fluorescent Screen Electrical Level Display

The overall design is according to business applying requirements of KTV compartment, with complete functions and excellent tone.

Microphone bass, alto voice and high pitch adjustment makes voice perfect.

Music Bass and High Pitch Adjustment.

Speaker System Protection, Overload Protection, High Temperature Protection, and Short-circuit Protection.

Model	FP14000
	Output Power
8Ω	2x2400W
4Ω	2x4800W
2Ω	2x6500W
Bridge 8Ω	8800W
Bridge 4Ω	14000W
Frequency Response	20Hz-25KHz (±0.5dB)
THD+N	<0.1%(rated power,4Ω,1KHz)
S/N Ratio	>110dB
Input Impedance	20KΩ Balanced/10KΩ Unbalanced
Damping Factor	800
Input Connector	3 pins XLR (NEUTRIK)
Output Connector	SPEAKON (NEUTRIK)
Protection	soft start, short, DC, over heat, RF, UHF, CPL
Power Supply	AC200-240V/50-60Hz
Dimension	483 x 380 x 88 mm
Packing Dimension	575x485x175mm
Net Weight(kg)	13
Gross Weight(kg)	14.5

High Fidelity Stereo Switching Power Amplifier FP 14000Q DJ Audio Amplifier Sound System
