Lab Gruppen 4 Channel Swithcing Power Class TD Amplifier FP6000Q for Concert Hall and DJ Equipment
FP 4 Channel Switching TD Technology Professional Power Amplifier
The FP series switching power amplifiers are Sanway innovative technology achievement. They are designed to achieve unsurpassed sonic performance and longterm reliability for operating even under extreme rigorous conditions. In addition, this workhorse of the amplifier is loaded with features including full short circuit open circuit, thermal and mismatched loads protection,and intelligent cooling system etc.
Feature :
1. switching power supply
High efficiency and stability of the new switching power supply
2. intelligent signal limiter
Each channel has an independent output signal overload distortion, automatic pressure lImited function, to avoid DC level because of the audio signal output and burned speakers.
3. multiple detection, multiple protection
A soft start, the second start, the (low) pressure protection, output overload and short circuit protection.
4. high efficiency, low fever
Efficient Class TD amplifier, significantly reduce heat loss.
5. Metal Packaging, high-power transistors, a pure, passionate, authentic audio effects.
6. removable face Network
Removable the hole into the wind-net, easy cleaning.
Applications :
1). Arenas
2). Convention Centers
3). Medium or large Ballrooms
4). Perfect for corporate
5). Theaters Music
6). Club or Church
7). Concert reinforcement
Specification:
| Model | FP6000Q |
| | Output Power |
| 8Ω | 4x640W |
| 4Ω | 4x1275W |
| 2Ω | 4x1500W |
| Bridge 8Ω | 2x2650W |
| Bridge 4Ω | 2x2800W |
| Frequency Response | 20Hz-25KHz (±0.5dB) |
| THD+N | <0.1%(rated power,4Ω,1KHz) |
| S/N Ratio | >90dB |
| Input Impedance | 20KΩ Balanced/10KΩ Unbalanced |
| Damping Factor | 800 |
| Input Connector | 3 pins XLR (NEUTRIK) |
| Output Connector | SPEAKON (NEUTRIK) |
| Protection | soft start, short, DC, over heat, RF, UHF, CPL |
| Power Supply | AC200-240V/50-60Hz |
| Dimension | 483 x 380 x 88 mm |
| Packing Dimension | 575x485x175mm |
| Net Weight(kg) | 12 |
| Gross Weight(kg) | 13.5 |
